The 3DMakerPro Whale is a high-performance handheld 3D scanner for ultra-large objects. Scanning from 500mm up to 3 metres with 0.20mm accuracy at 10fps, the Whale handles full vehicles, large industrial machinery, architectural elements, and oversized sculptures that exceed the range of standard handheld scanners. It is the right tool when the object to be digitised is simply too large for any other scanner in the 3DMakerPro range.

Key Specifications

Accuracy	Up to 0.20 mm
Resolution	Up to 0.50 mm
Scanning speed	Up to 10 frames per second
Object size range	500 mm – 3,000 mm
Scanning technology	Advanced optical structured light
Surface compatibility	Dark and reflective surfaces without spray coating
Tracking	Markerless intelligent tracking + optional marker mode
Software	JMStudio (included)
Export formats	OBJ, STL, PLY, ASC
Connection	USB

500mm to 3m — When the Object Is the Constraint

The Whale's 500mm–3m range covers digitisation tasks that are simply not possible with smaller scanners. A complete vehicle body, a large CNC machine, a full-scale statue, an industrial mould or die — these objects require the Whale's wider standoff distance and field of view. The 0.20mm accuracy delivers data precise enough for CAD comparison, quality inspection, and reverse engineering at this scale. For applications where a 1mm or 2mm error would be acceptable (visual digital twins, exhibition models, general spatial capture), the Whale provides excellent scan quality at a very fast working pace.

Designed for On-Site Scanning

Objects in the Whale's size range rarely come to the scanner — the scanner goes to them. Its handheld form factor, USB power, and robust construction make it practical for factory floors, outdoor environments, and large workshop spaces where the object cannot be moved to a controlled scanning station. The markerless tracking system maintains position during the continuous movement required when walking around a full vehicle or large machine.

JMStudio Software

JMStudio handles the large point clouds generated by Whale scans — real-time display, frame alignment, hole filling, and mesh optimisation before export to OBJ, STL, or PLY. Large scan files from full-vehicle captures are managed efficiently without requiring specialist high-memory workstations for most workflows.

What's in the Box

• 3DMakerPro Whale 3D scanner
• USB cable
• Calibration board
• Carrying case
• Quick start guide
• JMStudio software licence

Who It's For

• Automotive and motorsport teams digitising full vehicle bodies for aerodynamic analysis, bodywork design, and restoration
• Industrial manufacturers capturing large machinery, moulds, and tooling for quality inspection and reverse engineering
• Aerospace prototyping teams scanning large structural components and assemblies
• Artists and galleries digitising large sculptures and installations for archiving, reproduction, or digital display
• Construction and heritage preservation teams capturing large architectural elements and structural features

Available from Eolas Prints

Eolas Prints is an official 3DMakerPro distributor based in Cantabria, Spain, serving customers across Europe. EU warranty and support included.
