3DMakerpro Seal Lite 3D Scanner
The 3DMakerPro Seal Lite is a compact handheld 3D scanner for high-detail capture of small objects. Using blue light structured light technology and delivering 0.05mm accuracy at 10fps, the Seal Lite is an accessible entry point to precision small-object scanning — suited to jewellery, miniatures, consumer product reverse engineering, and educational 3D scanning projects where the full Seal's 0.01mm precision is not required.
Key Specifications
| Accuracy | Up to 0.05 mm |
| Resolution | Up to 0.10 mm |
| Scanning speed | Up to 10 frames per second |
| Object size range | 10 mm – 300 mm |
| Scanning technology | Blue light structured light |
| Surface compatibility | Shiny, dark, and intricate surfaces |
| Tracking | Markerless intelligent tracking |
| Software | JMStudio (included) |
| Export formats | OBJ, STL, PLY, ASC |
| Connection | USB |
Seal Lite vs Seal — Which to Choose
Both scanners use blue light technology and scan objects from 10–300mm. The key difference is accuracy: the Seal achieves 0.01mm, the Seal Lite achieves 0.05mm. For jewellery reproduction, dental applications, and engineering inspection where dimensional tolerances are tight, the Seal's extra precision matters. For most creative and maker applications — digitising figurines, small props, product casings, decorative objects — 0.05mm is more than sufficient and the Seal Lite offers the same workflow and software at a significantly lower price.
Blue Light Advantage on Small Objects
Blue light structured light technology reduces ambient light interference and improves fringe contrast at short scanning distances, where noise in the point cloud would be most visible. On small objects with fine surface texture — a textured grip, an embossed logo, a sculpted detail — this produces a cleaner mesh with better preservation of the original surface character than infrared systems at comparable working distances.
What's in the Box
- 3DMakerPro Seal Lite 3D scanner
- USB cable
- Calibration board
- Carrying case
- Quick start guide
- JMStudio software licence
Who It's For
- Makers and hobbyists digitising small objects for 3D printing or modification
- Jewellery designers capturing pieces for reproduction or resizing at an accessible price
- Educators introducing students to handheld 3D scanning workflows
- Artists digitising miniatures, collectibles, and small sculptures
- Product designers reverse engineering small consumer components
Available from Eolas Prints
Eolas Prints is an official 3DMakerPro distributor based in Cantabria, Spain, serving customers across Europe. EU warranty and support included.
