The xTool S1 is a fully enclosed, high-power diode laser cutter and engraver available in 20W and 40W configurations. Its Class 1 safety enclosure, integrated air filtration, and camera-assisted positioning system make it a professional-grade machine suited to demanding production environments — while remaining compact enough for a desktop workshop or small studio.

Key Specifications

Laser type	Diode laser — 20W or 40W
Work area	498 × 319 mm
Laser engraving speed	Up to 600 mm/s (20W) / 600 mm/s (40W)
Laser accuracy	0.08 mm
Enclosure	Fully enclosed — Class 1 certified safety design
Air filtration	Built-in air purification system
Camera	Dual cameras — panoramic and close-up for precise positioning
Passthrough	Front and rear slots for oversized material
Software	xTool Creative Space
Connectivity	USB, Wi-Fi

20W vs 40W — Choosing the Right Power

The 20W version handles the majority of craft and small business applications: cutting basswood up to 15mm, acrylic up to 12mm, and engraving leather, cork, fabric, and anodised metals at high speed. For most users, 20W is the practical choice.

The 40W version is built for heavier cutting workloads — basswood up to 25mm, acrylic up to 20mm, and faster throughput on thick materials. Choose 40W if your primary use case is production cutting of thicker stock, or if you need to maximise throughput on batch jobs.

Material Compatibility

• Cutting: Basswood, plywood, MDF, acrylic, leather, cardboard, paper, fabric, foam, felt
• Engraving: Wood, bamboo, leather, acrylic, anodised aluminium, slate, rubber, cork, coated metals, glass (surface marking)
• Not suitable for: PVC, polycarbonate, or materials containing chlorine — these release toxic gases when laser-cut

Class 1 Enclosure and Filtration

The S1's fully enclosed design achieves Class 1 laser safety certification — meaning the machine does not emit hazardous radiation externally during normal operation. This makes it suitable for offices, studios, classrooms, and shared workspaces where open-frame diode lasers would not be appropriate. The built-in air purification system removes fumes and particles at source, reducing the need for external ventilation ducting.

Passthrough Slots

Front and rear passthrough slots allow material longer than the 498mm work area to be fed through the machine progressively. Useful for cutting or engraving long planks, rolls of leather, and extended fabric pieces that would not fit in a closed work area.

Who It's For

• Small businesses and studios requiring a safe, enclosed laser for office or workshop use
• Gift and personalisation businesses with high-volume engraving workloads
• Woodworkers, leatherworkers, and makers needing a high-power diode laser for cutting
• Schools and educational facilities requiring a Class 1 certified machine

Available from Eolas Prints

Eolas Prints is an authorised xTool reseller based in Cantabria, Spain, serving customers across Europe. EU warranty and support included.
