The xTool M1 Smart is a 2-in-1 desktop machine that combines a 10W diode laser engraver with a precision vinyl cutter in a single enclosed unit. If you engrave on wood, leather, and acrylic — and cut vinyl, paper, and fabric — the M1 Smart does both without switching machines or moving your material between workflows.

Key Specifications

Laser type	10W diode laser
Cutting method	Blade cutting (vinyl cutter)
Work area	385 × 300 mm
Laser engraving speed	Up to 400 mm/s
Laser accuracy	0.08 mm
Enclosure	Fully enclosed — Class 1 eye-safe design
Camera	Built-in for object positioning and preview
Software	xTool Creative Space (Windows, Mac, iPad)
Connectivity	USB, Wi-Fi

Two Machines, One Footprint

The M1 Smart switches between laser and blade mode without manual head swaps — the tool modules are built in and selectable from software. Place your material once and execute a combined job: engrave a design with the laser, then cut the outline with the blade. This is particularly useful for personalised vinyl decals, layered paper art, heat transfer vinyl (HTV) garments, and mixed-media craft projects.

What the Laser Engraves and Cuts

The 10W diode laser handles a wide range of materials in the enclosed workspace:

• Engraving: Wood, bamboo, leather, acrylic, anodised aluminium, slate, rubber, cork, fabric
• Cutting: Basswood up to 8mm, MDF up to 5mm, acrylic up to 5mm, leather, paper, cardboard, fabric

The enclosed design filters fumes and blocks laser radiation — making it safer to use in home workshops, studios, and shared workspaces than open-frame laser machines.

What the Blade Cutter Handles

• Vinyl (standard, glitter, holographic, HTV)
• Paper and cardstock
• Fabric and felt
• Foam sheets

Camera-Assisted Positioning

The built-in camera lets you preview exactly where your design will land on the material before the job starts. Place an irregularly shaped piece of wood or leather, take a snapshot, and position your engraving accurately in software — no manual measurement or guesswork.

Who It's For

• Craft businesses producing personalised gifts, custom merchandise, and branded packaging
• Vinyl and HTV garment makers who also want laser engraving capability
• Makers and hobbyists who want both tools in a compact, enclosed desktop form factor
• Schools and makerspaces needing a Class 1 safe, contained machine

Available from Eolas Prints

Eolas Prints is an authorised xTool reseller based in Cantabria, Spain, serving customers across Europe. EU warranty and support included.
